Patton Smartnode 4961 Series VoIP ESBC

  • Patton 4961 Patton 4961
Smartnode Gateways are Build to Order. Please allow 3-5 day lead time.
Product Details
Manufacturer:
Patton
Model:
SN4961
SKU:
02-sn4961
Warranty:
1 Year

Configure and learn about your Patton Smartnode 4961 Series VoIP ESBC below!

Or call one of our VoIP Experts at (800) 398-8647 or via email at sales@voipsupply.com.

Configure Now

From: $2,099.99

To: $24,999.96

As Configured: $0.00

As Configured: $0.00

Solution Overview

Patton Smartnode 4961 Series VoIP ESBC

Patton Smartnode 4961 Series VoIP Enterprise Session Border Controller and IAD

The Patton Smartnode 4961 Enteprise Session Border Controller router and gateway supports both VoIP and analog PBX's while they connect simultaneously to the PSTN and ITSPs. The SN4961 is available in both single and quad T1/E1/PRI ports and up to 120 VoIP Channels. Specific models also offer G.SHDSL or X.21 connection to the WAN and Failover Relay. Most SN4961 models are field upgradeable so additional VoIP Channels can be unlocked with a license keycode. The SN4961 improves on the Smartnode 4960 with the addition of a high precision 5ppm clock source enabling first-line IP telephony services in demanding ISDN and DECT environments with reliable FAX and modem performance.

Patton Smartnode 4961 Overview

As enterprises move toward SIP-based Unified Communications, the SmartNode™ 4961 offers a seamless transition by simultaneously supporting VoIP and circuit-switched access to SIP and traditional telephony. Preserve your investment in legacy phone equipment while taking the next step toward Unified Communications. Least-cost call routing in Patton’s proven SmartNode™ VoIP solutions optimizes monthly expenses while flexible dialed-numbering plans maintain established business processes.

The Unified Communications Agent™ (UCA) provides any-to-any multi-path switching (simultaneous SIP, H.323, ISDN, and POTS calls with routing and conversion between TDM/PSTN and IP/Ethernet networks—plus T.38 and SuperG3 FAX) combined with dial-backup and IP-link redundancy for VoIP-and-data survivability. Provide VoIP-over-VPN security with voice encryption via IPsec with AES/DES strong encryption and automated keying via Internet Key Exchange (IKE), plus SIP Registrar for presence/reachability.

Advanced router functionality includes Patton’s DownStreamQoS™ delivering the clear advantage of secure, uninterrupted voice-and-data communication. Session border controller capabilities include transcoding for up to 64 channels. Reduce WAN-access bandwidth requirements by converting high-bandwidth G.711 calls on your LAN into lower-bandwidth G.723 calls for WAN transport. Ensure business continuity. Combining PSTN breakout with IP-link redundancy, SmartNode™ ensures voice-and-data survivability for reliable enterprise-class communications.

Patton’s unique high-precision clock enabling first-line IP telephony services in demanding ISDN and DECT environments with reliable FAX and modem performance. Additional options include built-in broadband access via 11.4-Mbps, 4-wire G.SHDSL.bis or serial X.21 reduces hardware costs, simplifies network architecture, and streamlines service and deployment.

Patton Smartnode 4961 Features:

See Patton Smartnode 4960 Datasheet

  • PSTN:
  • • Up to four T1/E1/PRI ports (NE/TE)
  • • Signaling support (ISDN DSS-1, NI-2, Q.SIG, CAS Robbed bit loop and ground start, E&M, immediate, wink, double wink)
  • • ISDN AOC/ECT
  • • ISDN speech, audio & data (Fax Gr 4, UDI 64, RDI64)
  • • ISDN supplementary services
  • • CAS protocols: RBS (Loop start, ground start, E&M wink, intermediate, double-wink) and R2/MFC-R2 (Q.400–Q.490 and Configurable country profiles)
  • VoIP:
  • • SIPv2 (SIP Info, Update, PRACK, Privacy, Refer)
  • • B2BUA
  • • Optional SIP Registrar
  • • H.323v4 (H.235, Early H.245, H.245 tunneling, fast-connect)
  • Broadband Access:
  • •4-wire G.SHDSL ITU-T G991.2, Annex A, B, F, G (OPTIONAL)
  • • Up to 11.4 Mbps
  • • PPPoE
  • • 8PVCs, each UBR, CBR or VBR-rt selectable
  • • I.610 OAM F4/F5 support
  • • G.994.1 (G.hs)
  • • Serial X.21 (OPTIONAL)
  • Voice Processing
  • • Codec G.711 a-law/mu-law, G.723, G.729ab, G.726, G727, T.38 fax relay (9.6 k, 14.4 k)
  • • G.711 transparent fax and bypass
  • • 128 ms echo cancellation
  • • transcoding for up to 64 channels
  • Call Routing and Services :
  • • Regular expression call routing and manipulation
  • • number blocking
  • • short-dialing
  • • digit collection, distribution and hunt groups
  • Data Interfaces:
  • •Dual 10/100/1000 TX Ethernet Ports
  • • Autosensing
  • • Auto-MDI
  • • Full-duplex
  • IP Routing :
  • •IP access router
  • • DHCP Client & Server
  • • RIPv2
  • • BGP
  • • VRRP
  • • Packet fragmentation
  • • Firewall
  • • NAT/NAPT RFC 1631
  • • Access Control Lists
  • • DMZ port
  • • IPSec VPN (Option)
  • IP Quality of Service :
  • •Voice priority
  • • DownStreamQoS™
  • • traffic management, shaping policing
  • • IEEE 802.1p, TOS, DiffServ labeling
  • • IEEE 802.1Q, VLAN tag insertion/deletion 4,096
  • Management :
  • •Web/HTTP, CLI with local console & remote Telnet access
  • • HTTP/TFTP configuration & firmware loading
  • • SNMP MIB II and product MIB
  • • SYSLOG
  • • Secure autoprovisioning for both firmware & unit/subscriber configuration
  • • Built-in diagnostic tools (trace, debug, call generator)
  • Single T1 Models

    The Smartnode 4961 is offered in single or quad T1/E1/PRI models. Models with a a single T1 port can have up to 30 VoIP Channels and are field upgradeable with a license code. This means upgradeable models can be expanded to meet your needs easily.

    Single T1 Models with Special Options

    Additional options include built-in broadband access via 11.4-Mbps, 4-wire G.SHDSL.bis or serial X.21 which reduces hardware costs, simplifies network architecture, and streamlines service and deployment.

    Quad T1 Models

    The Smartnode 4961 is offered in single or quad T1/E1/PRI models. Models with a 4 T1 ports can have up to 60 or 120 VoIP Channels and are field upgradeable with a license code. This means upgradeable models can be expanded to meet your needs easily.

    Quad T1 Models with Special Options

    Additional options include built-in broadband access via 11.4-Mbps, 4-wire G.SHDSL.bis or serial X.21 which reduces hardware costs, simplifies network architecture, and streamlines service and deployment. Also offered is a Failover Relay option on select models.
