CyberData 011146 SIP Paging Server with Bell Scheduler

Please allow for a 1 - 2 day lead time.

Availability: In stock

The CyberData 011146 SIP Paging Server with Bell Scheduler enables users through a single SIP phone extension, to access multiple zones for paging in a VoIP network. Read More
$591.00
keyboard_arrow_down
Options
Product Details
Manufacturer:
CyberData
Model:
011146
SKU:
02-112735
Warranty:
2 Years
MSRP Price:
$591.00
Tech Specs
Manufacturer:
CyberData
Model:
011146
# of Ethernet Ports:
1
Ethernet Port Speeds:
10/100
Protocols Supported:
SIP
Provisioning Options:
Web GUI
Wireless:
No
Mounting Option:
Rackmount, Desktop

CyberData 011146 SIP Paging Server with Bell Scheduler

The CyberData 011146 SIP Paging Server with Bell Scheduler enables users, through a single SIP extension, to access up to 100 zones for paging and bell scheduling for VoIP phone systems. The SIP Paging Server with Bell Scheduler has a built-in calendar-based bell scheduler that enables, through a secure web interface, scheduled bells and prerecorded messages to be sent to different multicast zones as well as to legacy analog paging systems.A second SIP extension can be configured as a night ringer playing a user-uploadable audio file. The V3 Paging Server allows direct connection to legacy analog paging amplifiers that require a "Page Port" type input that meets a balanced 600 Ohm 10Vpp signal or a 10k Ohm Hi-Z 2vpp signal. You can also take advantage of connections for a dry contact relay (page start output) and sense input (Fault Sense Input) for additional functionality. The easy-to-use, web-based configuration for the Cyberdata 011146 provides a graphical user interface to setup to 100 paging zones for IP paging with unique multicast address and port number combinations. The V3 Paging Server connects via a single CAT 5 or 6 network cable to a standard PoE 802.3af compliant switch. Users who have purchased the SIP Paging Server with Bell Scheduler in the past two years, and have a unit with a serial number that begins with 1462, can upgrade their device for free and receive these new features now. Go to the CyberData website and click on the Downloads tab to get your firmware upgrade.

011146 SIP Paging Server with Bell Scheduler Features:

  • Calander-based Scheduler
  • Multi-user Login Capabilities
  • Call-in Recording for Stored Messages
  • SIP RFC 3261 compatible
  • Multicast output
  • Two SIP endpoints (one for Night Ringer)
  • DTMF control of zone selection
  • Delayed Page Support
  • Line-In connection for music on hold multicasting
  • Line-out connection to support analog Amps
  • User uploadable audio files
  • Web-based configuration and firmware upload
  • Ethernet I/F 10/100 Mbps
  • PoE 802.3af OR 48vdc
  • 19in rack mount option
