RayTel Motorola Dial-Up Modem TEL-6209548100010

The RayTel Motorola V.3600 is a powerful V.34/V.42 bis data and fax modem, enabling users to transmit essential applications at speeds of 33.6 kbps in both synchronous and asynchronous environments. It supports throughput rates of up to 230.4 kbps.

The V.3600 modem, compliant with ITU-T V.34 standards, incorporates advanced technologies to optimize performance on suboptimal transmission lines. These features include echo cancellation, automatic adaptive line equalization, trellis coding, adaptive transmit power selection, constellation shaping, and nonlinear encoding and precoding.

The V.3600's LCD front panel offers intuitive fingertip control for selecting options and configuring the modem. Its 32-character display and three push-button keys allow users to navigate a comprehensive menu, view current settings, and make adjustments easily. Additionally, the modem supports configuration via AT commands or remote configuration. Nine factory-preset option configurations simplify setup for common applications.

RayTel Motorola Dial-Up Modem TEL-6209548100010 Features & Specifications:

• Standards-Based Modulation: Supports ITU standards like V.34, V.32bis, and Bell 212A/103.
• Advanced Transmission Technology: Enhances performance on poor lines with echo cancellation and adaptive features.
• User-Friendly Design: LCD with push-button keys for easy menu navigation and configuration.
• Flexible Configuration: Supports AT commands, remote setup, and nine factory presets.
• Remote Management: Secure remote configuration over phone lines.
• High-Speed Fax: Compatible with ITU-T Group III fax devices.
• Automatic Rate Adaption: Dynamically adjusts data rates for line conditions.
• Security & Backup: Password-protected callback and dial backup for leased lines.
• Error Correction: Supports V.42 bis for reliable data transmission.
• Fully Automated Functions: Autodial, auto answer, and call progress indication.
• Mounting Options: Available as a standalone unit or rackmount card.
