Sangoma Remora A40600DE 12FXS PCI Express Card with Echo Cancellation

Become A Sangoma Reseller Today
Become A Sangoma Reseller Today Become A Sangoma Reseller Today Become A Sangoma Reseller Today Become A Sangoma Reseller Today Become A Sangoma Reseller Today Become A Sangoma Reseller Today
$1,456.00

Log in for lower price

Availability: In stock
SKU
02-104311
MPN
A400-A40600DE
MSRP
$1,456.00
The Sangoma A40600DE KIT is a PCI Express telephony card with 12 FXS Ports, no FXO Ports, and onboard echo cancellation.

Sangoma A400 Remora Analog PCI Cards

The A400 and Remora™ System Support up to 24 FXO/FXS ports.

The A400 Series is the high density version of the popular A200 series analog cards. Identical in operation and configuration, and using the same FXO and FXS modules, the A400 system supports twelve ports per main board and Remora™ daughtercard, as compared to four ports for the A200.

Sangoma Remora A400 Series FXS/FXO Analog PCI Cards

As you need them, additional Remora™ cards can be added to the base twelve-port A400 card. A single PCI or PCI Express slot host connection can support up to 24 FXO/FXS ports with common synchronous clocking for all channels.

The Sangoma A400 Card consists of an A400 Remora™ daughterboard mounted on the Sangoma AFT Series PCI or PCI Express base card. The A400 Remora™ Card has six sockets each, which can accept an FXO-2 or FXS-2 module. Each FXO-2 or FXS-2 module supports two FXO or FXS lines respectively.

Up to one additional A400 Remora™ daughterboards can be mounted in empty slot positions beside the A400 Remora™ assembly. These additional Remoras are connected to the A400 by a backplane bus connector.

Each 12-port A400 Remora™ card has a robust DB25 connection to a standard 12-line, colour-coded telephone cable that is ready for hard wiring into a punch block at the PSTN connection. Cable is included.

Like all the Sangoma AFT Series, the A400 and Remora™ system has field upgradeable firmware to take advantage of enhancements as they become available.

Sangoma cards guarantee error-free faxing and click-free audio on analog-digital links.*

*Hardware echo cancellation option required.

Didn't find the Sangoma PCI Card you were looking for? Check out our complete selection of Sangoma cards or try our easy to use Digium Configurators:

More Information
SKU 02-104311
Shop By Brand Sangoma
UPC 680031528836
Model A400-A40600DE
MPN A400-A40600DE
MSRP $1,456.00
Manufacturer Warranty Lifetime
# of FXS Ports 12
# of FXO Ports 0
Connection Types DB-25
Bus Type PCI-Express
Echo Cancellation Yes
