Patton SN4114 4-FXO VoIP Gateway SN4114/JO/EUI

Availability: In stock

Your Price: $296.99
Your Price: $296.99
The Patton SmartNode 4114 VoIP Gateway integrates up to 4 legacy PSTN, PBX, or standard phone lines with the next-generation IP Based telephony systems. Read More
Product Details
MSRP Price:
% Off:

Patton SN4114/JO/EUI 4FXO Gateway

The SmartNode 4110 VoIP Gateway supports up to 4 FXO telephone connections. Connect PSTN Lines for bridging a VoIP network to the PSTN. Now the corporate, small, or remote office can access Internet telephony services, eliminate toll charges and route calls to and from the PSTN, Internet, or LAN.

Quad Port FXO VoIP/VoIP Gateway, 1x10/100baseT, H.323 and SIP,external UI power (100-240VAC)

The SmartNode 4114 VoIP Media Gateway supports up to 4 transparent phone calls while leveraging VoIP for lower-cost carrier and corporate access. Connecting to the PSTN, the SN4114 analog gatewayis an effective and flexible solution for toll-bypass, remote/branch office voice connectivity, and enhanced carrier services.

The SN4110 series of Patton Gateways is the perfect choice for phone-to-IP connectivity supporting up to 8 FXS ports or a combination of 4 FXS and 2 or 4 FXO ports. This model, the SN4114/JO/EUI, has 4 FXO ports.With its FXS analog ports the SN4110 connects to any legacy telephone or PBX and provides dial-tone, ringing, and caller-ID. When equipped with FXO ports, the local PSTN can be accessed enabling local calling and enhanced toll-bypass applications while using a single connected telephone. Flexible call integration allows per-port telephone numbers, programmable call progress tones, and distinctive ringing. With Telephony-over-IP (ToIP) call switching, calls can automatically select the least-cost-route while providing flexible numbering plans and end-to-end feature transparency. PPPoE, DHCP, and VLAN offers universal IP connectivity and optional IPSEC VPN with AES/3DES guarantees secure voice over the public network.

Patton's SmartNode 4110 delivers the legacy phone interfaces, service transparency, and flexible PSTN integration for true converged packet voice.

  • 10/100 Full-Duplex Auto-Sensing Auto-MDX Ethernet port
  • 14 LEDs for System, Ethernet, and Call status
  • Universal 100-240VAC (contact us for 48VDC Power)
  • Configuration and Management through Webinterface, CLI, Telnet, Console and SNMP
  • Up to 8 Voice and FAX Calls over IP Support-Use any CODEC or T.38 FAX on any port, any time
  • 2,4,6 or 8 FXS ports connect to your standard telephone with programmable tones, ringing, CLIP etc.
  • 2 or 4 FXO ports connect to a PBX or the PSTN.
  • Programmable call routing switches between any FXS, FXO and IP connection.
  • Toll Quality CODECs and T.38 FAX-Use standard G.711 or G.726 Codecs for toll-quality or G.723.1 or G.728ab for low-bandwidth applications. T.38 FAX and FAX Bypass features allow high-quality FoIP.
  • H.323v4, SIP Signaling-Deploy into any enterprise or carrier softswitch network with the leading call and session signalling protocols. Maximize Interoperability to create advanced multimedia and messaging services.

# of FXO Ports
Connection Types
# of Ethernet Ports
Protocols Supported
SIP, H.323
Provisioning Options
Auto Provisioning, Console CLI, HTTP, TFTP, Web GUI
Modular Slots
MWI Support
Peripheral Port
PSTN Fallback / Failover
PSTN Signalling Support
FXO loop start
 Patton SmartNode 4114 VoIP Gateway

Michael Rehac

Direct: 716-213-6898

Why Pay $296.99 for the Patton SN4114 4-FXO VoIP Gateway SN4114/JO/EUI?

  • Easy Management & Provisioning—Web-based management, SNMP, command line interface. Automated mass provisioning for efficient large-scale deployments.

  • Advanced Local Call Switching—Virtual interfaces and routing tables provide industry leading flexibility in call handling programming. Local call switching, soft fallback to alternative routes. Simultaneously connects to multiple SIP services/IP PBXs.

  • 4 FXO ports—Compact, reliable stand-alone VoIP gateway with different port options. Supports simultaneous voice or fax calls on all ports.

For advice, reviews and industry insight... be sure to follow us online.

Questions on Patton SN4114 4-FXO VoIP Gateway SN4114/JO/EUI

From jlt at 12/28/2015 7:00 PM

Q: Hi
Is it possible with N4114 4-FXO to use FXO for incoming calls and transmit to asterisk DID numbers ?

A: the FXO gateway accepts the analog call, then sends the call via SIP to your Asterisk PBX. You can either build a non registering trunk and use inbound routes, or register each FXO port to an extension on the PBX and route the calls that way.

Do you find this question helpful?  Yes   No

From Vaughn T Hazell at 8/6/2016 8:00 PM

Q: what is the weight and dimensions of the shipping package

A: Hi Vaughn,

Product Dimensions 15 x 10.3 x 3.9 inches
Item Weight 2.9 pounds
Shipping Weight 3.8 pounds

Please contact our sales experts to further assist you!

Thank you for choosing VoIP Supply!


Do you find this question helpful?  Yes   No

From Allen A at 7/27/2017 8:00 PM

Q: Does this box with with Skype for Business?

A: Allen.

Thank you for choosing VoIP Supply!

Your VoIP Solutions Experts!


I have submitted your inquiry to one of our sales experts! Someone will be in contact with you shortly.

Do you find this question helpful?  Yes   No

Have a Question?

Add Your Review

  1 2 3 4 5

Customer Reviews

(Submitted on ) | by

Works well. Relatively easy to set up.

(Submitted on ) | by

Works just OK
I purchased this product because of the new Microsoft Lync certification. Configuration is tough, nearly impossible if you try to follow the enclosed manual.

Documentation for use with Lync is nearly non existent, it will require communication with Patton support for configuration.

Dropped calls have been an issue, but this may still be part of the configuration issues, trying to get it to work with analogue lines provided by a cable service.

The price entry may move to more stars once it is actually proven to work well.

(Submitted on ) | by

Works great - really tough to configure
I purchased this to gateway 4 POTS lines to a 3CX, Windows based soft-PBX I implemented. 3CX "recommends" this particular product and model, and that was the main reason I purchased it. With that being said, the "auto configure" feature built into 3CX to get this gateway to work with it really didn't get the job done. From there, it was a lot of trial-and-error with many settings before I got it working reliably. From that time, it has been great, working almost all the time (not 100%, but close enough), but just make sure you are confident with configuring gateways before getting this, as it is NOT very intuitive.
